Optipower is 3C3®’s hybrid fiber power cable system: single-mode fiber for data and copper conductors for power in one cable, keeping remote cameras, sensors and access points connected over long distances, in the most demanding environments.
Our powered-fiber solutions merge power and data transmission into one robust cable, drastically reducing installation complexity and cutting maintenance costs. This approach streamlines your infrastructure and ensures remote devices – from cameras and IoT sensors to wireless access points – stay reliably connected.
Engineered for challenging environments, Optipower delivers high-speed connectivity over long distances. Experience uninterrupted data flow and efficient power delivery across industries from surveillance and agriculture to smart cities and industrial automation.
A camera 2 km down a highway, a sensor at the far end of a farm or a Wi-Fi point on a mine haul road usually needs two things that are hard to get there: a data link and a power supply. A hybrid fiber power cable delivers both in one run, so there is no local power connection to arrange at each device. 3C3 makes the hybrid cable, base unit and outdoor enclosures as one tested system.
Five application-focused solutions, each combining power and data delivery in one fiber-optic infrastructure – built for reliability, efficiency and scale.
Robust hybrid connectivity for extreme mining environments - reliable power and high-speed data across rugged terrain, optimizing safety and efficiency.
Power and data for HD cameras and sensors - uninterrupted, low-latency connectivity for 24/7 monitoring.
Connectivity for IoT devices and WiFi - simplified deployment, efficient power management and rapid data transfer.
Every Optipower link uses four parts. The base unit in your equipment room puts data and power onto the hybrid cable; at the far end, an outdoor enclosure turns them back into PoE for the devices.
| Part | What it does | Key specifications |
|---|---|---|
| Opti Power Base Unit, 1U | Takes Ethernet from your switch and puts data and power onto the hybrid cable | 1 × GbE RJ45 in, 1 × hybrid fiber-copper out, 57 VDC / 750 W supply, 1.25G single-mode 10 km SFP (LC) |
| Hybrid cable | Carries data and power in one run | 4 single-mode fibers (G.657A1, bend-insensitive) + 4 × 12 AWG copper conductors |
| Opti Power Outdoor Enclosure | Powers and connects cameras, sensors and access points at the far end | 4 × 90 W PoE (IEEE 802.3bt) or 4 × 30 W PoE, 2 × SFP, 2 × RJ45, 12–56 VDC input |
| PoE surge protectors | Protect exposed runs from surges and lightning | IP65 outdoor unit; 16- and 24-port 19-inch rack units |
Optipower integrates electrical power and optical data into a single hybrid run – extending reliable, powered connectivity far beyond the reach of standard copper.
Electricity and high-speed fiber in one cable.
Reaches far past the ~100 m limit of PoE.
Simpler design, lower install and maintenance cost.
Powers cameras, IoT sensors and access points anywhere.
Three ways to connect a remote camera, sensor or access point, compared.
| Copper PoE | Fiber + local power | Optipower hybrid cable | |
|---|---|---|---|
| Data reach | 100 m | Kilometres | Up to 10 km with the base unit's SFP |
| Power at the device | From the switch | Needs a mains supply at each point | Carried in the same cable |
| Cables per site | One | Two (fiber + power) | One |
| Lightning and interference | Copper data is exposed | Fiber data is immune | Fiber data is immune; surge protectors guard the power |
How far power can travel depends on the load at the far end and the voltage drop on the copper; our team calculates it for each site before you order.
Fiber data with very low signal loss over long distances.
Efficient power delivery to far-flung devices.
One cable means less complexity and cost.
Performs in remote, demanding environments.
Power and data for cameras and sensors along haul roads and pits.
HD cameras on highways, perimeters and city streets from one cable.
Outdoor access points and sensors without a local power point.
Cameras and Wi-Fi across large university and industrial campuses.
Field cameras and sensors spread across farms.
Poles, junctions and public spaces that need power and connectivity.
3C3’s powered fiber – a single hybrid cable carrying electrical power and high-speed optical data, so remote cameras, IoT sensors and access points get power and connectivity over one run.
PoE is limited to ~100 m over copper. Powered fiber pairs optical data (far longer reach, very low signal loss) with copper power conductors, extending powered connectivity over much longer distances
One cable for power and data simplifies design, cuts install complexity and lowers maintenance – with high-speed connectivity and reliable power to remote devices.
Demanding/remote environments – mining, surveillance, IoT/WiFi, large campuses and farms – anywhere devices are far from power or a switch.
Mining, Surveillance, IoT & WiFi, Campus Network and Agro Tracking.
Yes – make in India and backed by ISO 9001/14001/45001 and ETL.
Data runs up to 10 km over the single-mode fiber with the base unit’s SFP. The distance power can travel depends on how much the devices at the far end draw and the voltage drop on the 12 AWG copper, so our team calculates it for each site.
The Opti Power Outdoor Enclosure comes in two versions: four 90 W IEEE 802.3bt PoE ports for PTZ cameras and multi-radio access points, or four 30 W PoE ports for fixed cameras and sensors. Both add two SFP and two RJ45 ports.
See how Optipower powered-fiber connectivity can transform your infrastructure with scalable performance tailored to your site.
