| Housing Material | Zinc-Alloy, Fully Shielded |
| Plug Contact | T = 0.35 mm Phosphor Bronze |
| Contact Area | Gold over Nickel Plating |
| IDC Contact | T = 0.4 mm Phosphor Bronze, Sn over Nickel Plating |
| Operating Temperature | −40°C to +70°C |
Category 6A Field Terminate Plug are designed for use on Solid cable assemblies and strand conductors of sizes from AWG 23 through AWG 26. This plug design accommodates large diameter cabling in the form factor of a standard RJ45 plug. FTP offers a distinct approach for connectivity for an IP-enabled IoT devices/ PoE enabled devices. Developed under MPTL for delivering custom-length cables to be terminated on-field locations for direct connections to end point devices. FTP exceeds all Category 6A performance requirements to easily support high-speed applications like 5GHz Wi-Fi and High resolution Video cameras.
| Housing Material | Zinc-Alloy, Fully Shielded |
| Plug Contact | T = 0.35 mm Phosphor Bronze |
| Contact Area | Gold over Nickel Plating |
| IDC Contact | T = 0.4 mm Phosphor Bronze, Sn over Nickel Plating |
| Operating Temperature | −40°C to +70°C |
