| Conductor AWG | 23 |
| Conductor Material | Solid Bare Copper |
| Outer Sheath | LSZH |
| Overall Cable Diameter | 7.5 ± 0.4 mm |
| Operating Temperature | −20°C to +70°C |
| Storage Temperature | −20°C to +70°C |
High Speed 10Gigabit Ethernet S-FTP 500 MHz Class EA / Category 6A LSZH Cable is produced using 8×23 AWG Solid Bare Copper Conductors. Every pair is separately shielded – pairs in metal foil (PIMF). The twisted pairs are covered with a braided screen (S/FTP) which guarantees outstanding shielding properties and then LSZH Outer Sheath. It supports 10/100/1000Base-T, 155Mbps ATM, IEEE 802.3an (10GBase-T) Standard.
| Conductor AWG | 23 |
| Conductor Material | Solid Bare Copper |
| Outer Sheath | LSZH |
| Overall Cable Diameter | 7.5 ± 0.4 mm |
| Operating Temperature | −20°C to +70°C |
| Storage Temperature | −20°C to +70°C |
