| Conductor AWG | 23 |
| Conductor Material | Solid Bare Copper |
| Inner Sheath | PE |
| Outer Sheath | LSZH |
| Overall Cable Diameter | 10.5 ± 0.5 mm |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -20°C to +60°C |
High Speed Gigabit Ethernet UTP 250MHz ECCS Armoured Class E / Category 6 Cable Consists of HDPE Insulated 8 x 23AWG Solid Bare Electrolytic Grade Copper Conductors Twisted as 4 Pairs, LSZH Inner Sheath, Electrolytic Chrome-coated Corrugated Steel Tape Armouring covered with PE Outer Sheath. This cable offers superior Electrical performance meeting 1000Base-T requirement. 3C3® Armoured cables can be used for wide range of industrial environments/application that requires no signal drops or interference.
| Conductor AWG | 23 |
| Conductor Material | Solid Bare Copper |
| Inner Sheath | PE |
| Outer Sheath | LSZH |
| Overall Cable Diameter | 10.5 ± 0.5 mm |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -20°C to +60°C |
