ECCS Armoured

Part Code:

10201-0026

High Speed Gigabit Ethernet U/UTP 250MHz Class E, ECCS Tape Armored, Inner FRPVC, Outer PE, Outdoor Cable, C6.
Conductor AWG 23
Conductor Material Solid Bare Copper
Inner Sheath PVC
Outer Sheath PE
Overall Cable Diameter 10.5 ± 0.5 mm
Operating Temperature −20°C to +75°C
Storage Temperature −20°C to +70°C
Download datasheet
Enquire about this product
  • 3C3® Performance Warranty
  • Make in India

High Speed Gigabit Ethernet UTP 250MHz ECCS Armoured Class E / Category 6 Cable Consists of HDPE Insulated 8 x 23AWG Solid Bare Electrolytic Grade Copper Conductors Twisted as 4 Pairs, PVC Inner Sheath, Electrolytic Chrome-coated Corrugated Steel Tape Armouring covered with PE Outer Sheath. This cable offers superior Electrical performance meeting 1000Base-T requirement. 3C3® Armoured cables can be used for wide range of industrial environments/application that requires no signal drops or interference.

  • Complies to ANSI-TIA 568.2-D for Category 6, ISO/IEC 11801 for Class E.
  • Cable Characterized up to 250 MHz.
  • Electrolytic Chrome-coated Corrugated Steel Tape Armoring.
  • Maximum throughput, reliability and performance.
  • 4 Pair Separator Design.
  • UL Listed and Channel performance Verified by ETL.
  • Covered under 3C3® Performance Warranty.
Conductor AWG 23
Conductor Material Solid Bare Copper
Inner Sheath PVC
Outer Sheath PE
Overall Cable Diameter 10.5 ± 0.5 mm
Operating Temperature −20°C to +75°C
Storage Temperature −20°C to +70°C

Request a quote

Enquire about this product

Tell us your requirement for the

ECCS Armoured

Part Code: 10201-0026

and our team will get back with pricing, lead time and datasheets.
