GI Armoured cable

Part Code:

10201-0016

High Speed Gigabit Ethernet UTP 250 MHz Class E GI Armored, Inner FRPVC, Outer FRPVC, Outdoor Cable,C6.
Conductor AWG 23
Conductor Material Solid Bare Copper
Inner Sheath PVC
Outer Sheath FRPVC
Overall Cable Diameter 9.60 ± 0.50 mm
Operating Temperature −20°C to +75°C
Storage Temperature −20°C to +70°C
Download datasheet
Enquire about this product
  • 3C3® Performance Warranty
  • Make in India

High Speed Gigabit Ethernet GI Armoured UTP 250MHz Class E / Category 6 Cable Consists of HDPE Insulated 8 x 23AWG Solid Bare Electrolytic Grade Copper Conductors Twisted as 4 Pairs, PVC Inner Sheath and Galvanized Iron Wires Covered with FRPVC Outer Jacket. This cable guarantees superior Electrical performance meeting 1000 Base-T requirement for Outdoor Applications.

  • Complies to ANSI-TIA 568.2-D for Category 6 & ISO/IEC 11801 for Class E.
  • Cable Characterized up to 250 MHz.
  • Galvanized Iron Wire Armoring.
  • 4 Pair Separator Design.
  • UL Listed and Channel performance Verified by ETL.
  • Covered under 3C3® Performance Warranty.
Conductor AWG 23
Conductor Material Solid Bare Copper
Inner Sheath PVC
Outer Sheath FRPVC
Overall Cable Diameter 9.60 ± 0.50 mm
Operating Temperature −20°C to +75°C
Storage Temperature −20°C to +70°C
