MPO to LC Uniboot Duplex Breakout Cable

Partcode: 67CDE-XXXX

Description: MPO to LC Uniboot Breakout patch cord

The MPO to LC breakout cabling system is an ideal solution for high‑density environments that require space‑saving cable layouts and efficient cable management. MPO connectors support multiple fiber connections within a single cable, enabling data center designers to deploy ten to twenty times more fiber strands in the same physical space. By simply installing an MPO trunk cable within the facility and connecting it to the rear of an MPO patch panel or a fan‑out module, a streamlined and scalable cabling infrastructure can be achieved.

Features

  • Conformance to Telcordia GR-1435 Core, ANSI/TIA-568.3-E, ANSI/TIA 604-5, IEC 61754-7
  • High precision guide pins for exact alignment
  • Plug and Play
  • High Density interconnect with 8F, 12F options
  • Single-Mode and Multi-Mode color coded housings
  • Removable housing for quick change of pin clamps and easy ferrule cleaning/re-polishing
  • Alignment achieved with high precision guide pins
  • True Uniboot (one boot) design and Polarity change option for LC
  • Standard breakout length 24inch (Customized options are available)
  • Covered under 3C3® Performance Warranty

Specifications

Connector Type: LCU Uniboot

Operating Temperature: -40°C to +85°C

Type Wavelength I.L Type I.L Max R.L Min
MPO /PC (MM) 850nm/1300nm 0.25dB 0.35dB ≥30dB
MPO/APC (SM) 1310nm/1550nm 0.25dB 0.35dB ≥50dB
