Multimode Indoor/ Outdoor Fiber Optic Cable (96F)

Part Code:

52C22-0096

High Link Fiber Optic, Multi loose Tube Indoor/Outdoor Cable, Gel free, 6F/T, CSM FRP, Single Sheath Black LSZH, MM, 96 cores.
Fiber Count 96
Fibers per Loose Tube 12
Outer Sheath LSZH
Nominal Cable Diameter 10.5 ±0.5 mm
Drum Length 2 km ±5%
Operating Temperature -40°C to +70°C
Storage Temperature -40°C to +70°C
Download datasheet
Enquire about this product
  • 3C3® Performance Warranty
  • Make in India

The Indoor/outdoor fiber optic cables are PBT Multi loose tube with colored fiber cores. The constructions are of dry water-blocking material with Non-Metallic Central Strength member. This cable has LSZH outer jacket and makes it perfect for indoor/outdoor applications.

  • Complies to ANSI/TIA-568.3-D, Telcordia GR-20, IEC 60794-2, ISO/IEC 11801, ISO/IEC 24702.
  • Waterproof layer & excellent moisture resistance provided.
  • Excellent consistent performance.
  • Covered under 3C3® Performance Warranty.
Fiber Count 96
Fibers per Loose Tube 12
Outer Sheath LSZH
Nominal Cable Diameter 10.5 ±0.5 mm
Drum Length 2 km ±5%
Operating Temperature -40°C to +70°C
Storage Temperature -40°C to +70°C
