Single Mode Direct Burial Armoured Fiber Optic Cable 96

Part Code:

55011-0096

High Link Fiber Optic, Double Armoured, Multi loose Tube Outdoor Direct Burial Cable, Gel filled, 6F/T, CSM FRP, Double Sheath Inner HDPE Outer Black HDPE, OS2, 96 Cores.
Fiber Count 96F
Fibers per Loose Tube 12
Inner Sheath HDPE
Outer Sheath HDPE
Nominal Cable Diameter 14.0 ± 0.5 mm
Drum Length 2 km ± 5%
Operating Temperature -40°C to +70°C
Storage Temperature -40°C to +70°C
Download datasheet
Enquire about this product
  • 3C3® Performance Warranty
  • Make in India

Single Mode Multi Loose Tube, Double Sheath, optical fiber cables are prefect for direct burial applications. These cables are perfectly suited for both gigabit Ethernet and 10 gigabit Ethernet campus and backbone applications.

  • Conformance to ANSI/TIA-568.3-D, ITU-T G652.D, Telcordia GR-20, IEC 60794-3-10.
  • Excellent water proof layer and good moisture resistance.
  • Excellent consistence performance.
  • Covered under 3C3® Performance Warranty.
Fiber Count 96F
Fibers per Loose Tube 12
Inner Sheath HDPE
Outer Sheath HDPE
Nominal Cable Diameter 14.0 ± 0.5 mm
Drum Length 2 km ± 5%
Operating Temperature -40°C to +70°C
Storage Temperature -40°C to +70°C

Product Specification

Detailed Datasheet
