| Fiber Count | 24F |
| Fibers per Loose Tube | 6 |
| Outer Sheath | LSZH |
| Nominal Cable Diameter | 12.5 ± 0.5 mm |
| Drum Length | 2 km ± 5% |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +70°C |
The Outdoor fiber optic cables are PBT Multi loose tube with colored fiber cores. The constructions are of water-blocking gel material with Non-Metallic Central Strength member & ECCS armoring. This cable has LSZH outer jacket makes it perfect for outdoor applications.
| Fiber Count | 24F |
| Fibers per Loose Tube | 6 |
| Outer Sheath | LSZH |
| Nominal Cable Diameter | 12.5 ± 0.5 mm |
| Drum Length | 2 km ± 5% |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +70°C |
