Category 6 SF-UTP Cable – FRPVC

Part Code:

10222

High Speed Gigabit Ethernet SF-UTP 250 MHz Class E FRPVC Cable, C6.
Conductor AWG 23
Conductor Material Solid Bare Copper
Outer Sheath FRPVC
Overall Cable Diameter 7.20 mm
Operating Temperature −20°C to +60°C
Storage Temperature −20°C to +75°C
Download datasheet
Enquire about this product
  • 3C3® Performance Warranty
  • Make in India

High Speed Gigabit Ethernet UTP 250 MHz Class E / Category 6 Cable Consists of HDPE Insulated 8 x 23AWG Solid Bare Electrolytic Grade Copper Conductors Twisted as 4 Pairs, Al-Mylar Tape with Drain Wire, overall Aluminum braiding and FRPVC Outer Jacket. This Cable is Suitable for Gigabit Ethernet (1000Base-T) applications for High-Speed Data, Voice & Video Signals over LANs, Server Farms and Other Bandwidth Sensitive Indoor Applications.

  • Complies to ANSI-TIA 568.2-D for Category 6 & ISO/IEC 11801 for Class E.
  • Fire Rating as per IEC 60332-1.
  • Cable Characterized up to 250 MHz.
  • Shielded with Al-Mylar Tape with Drain Wire.
  • Overall, Alloy Braiding.
  • Maximum throughput, reliability and performance.
  • 4 Pair Separator Design.
  • Covered under 3C3® Performance Warranty.
Conductor AWG 23
Conductor Material Solid Bare Copper
Outer Sheath FRPVC
Overall Cable Diameter 7.20 mm
Operating Temperature −20°C to +60°C
Storage Temperature −20°C to +75°C
