FTTA termination Box

FTTA termination Box

Partcode: 840DE-XXXX

Description: FTTA Enclosure, Loaded

The FTTA Pre connectorized factory sealed Plug and play fiber optic enclosure allows easy and quick installation of cables. The fiber splitting and distribution can be done in this box, and it provides solid protection and management for the FTTA network building.

Download Data Sheet

Features

  • Support both wall and Pole mounting
  • IP 68 rated
  • Accommodate 1×4 PLC and 1×8 PLC ,1x 16 PLC and 1x 24 PLC Splitters
  • Industry Standard User interface and made of high impact plastic
  • Anti-UV, Ultraviolet resistant and rainfall resistance
  • Covered under 3C3® Performance Warranty

Specifications

Material : PC
Fiber Capacity Maximum : 8F
Adapter Types : SC/LC
Job stress : 70kpa to 108 kpa
Operating Temperature : -40°C ~ +80°C
Cable OD : 6.0mm to 12.0mm
Relative Humidity : ≤ 95%
Protection : IP68
Dimension (L xW xH) : 225 X 120 X 85mm(4F), 305 X 120 X 85mm(8F), 416 X 120 X 85mm(12F)
