Giga Core™ Standard Panel 1U 96 Fiber

Partcode: 61902-1000

Description: Giga Core™ Standard Panel 1U 96 Fiber

The Fiber Optic Sliding Patch Panel 1U with 4Cutout are innovative, robust and have been designed to accept up to 4 style assemblies. With the ability to use a full array of adaptor types, this panel offers a flexible solution to the end user, enabling them to incorporate a multi- functional chassis that allows easy access during installation or rework with no disturbance to the existing cable or fibers. In addition to the array of adaptors, the panel also offers multiple cable entry solutions, MPO trunk cables connected to 4 individual MPO cassettes with up to 24 fibers in each, loose tube cable to be spliced into standard splice cassettes to allow standard splicing or pre terminated solutions, making this panel one of the most flexible on the market.

Download Data Sheet

Features

Features – Panel
• Complies to IEC61754-7, ANSI/TIA-604-5 FOCIS 5, ISO/IEC 11801
• Standard 19-inch Rack Mountable
• Unique slide design, structural stability, easy to use and operate, slides smoothly without interference.
• Accepts 4 x 24Fiber & 4 x 12Fiber MPO Cassette, 4 x 6 MPO Adapter Plate,4 x 6LC Quad
• 4 Nos of 20mm diameter at the rear for Cable entries
• Covered under 3C3® Performance Warranty
Features – MPO Adapter & Cassette Module
• Cassette is made of SPCC Sheets.
• Flexible configuration, installation fast.
• Pull buckle fixed, installation MPO adapter.
• 12F Cassette: 6LC Duplex at front and 1x12F MPO at rear
• 24F Cassette: 6LC Quad/12 Duplex at front and 2x12F MPO at rear
• 6 MPO Adapters per Plate -12F/24F
Features – Blank Plate
• Material: SPCC (cold rolled steel sheet)
• Color Black
• Size: 129 X 30 X 1.5 mm

Specifications

Material: SPCC(Cold rolled steel sheet)
MPO-LC (MM) : 0.75dB (I.L Max)
MPO-LC (SM) : 1.50dB (I.L Max)
Operating Temperature : -25ºC ~ +70ºC
