Opti Power Outdoor Enclosure

Opti Power Outdoor Enclosure

Partcode: 87310-001-0000

Description: Opti power Outdoor Enclosure, 4*30W PoE, 2*SFP, 2*RJ45 Switch with 12-56VDC input

The Opti power Enclosure comprises robust industrial-grade PoE switches designed for outdoor deployments, offering IP67-rated protection and 6KV PoE surge protection to ensure reliability in harsh conditions. These switches support flexible uplink options with SFP transceivers and provide data rates of up to 1Gbps. Housed in an IK10-rated aluminum enclosure, these switches are ideal for powering and connecting outdoor IP cameras, wireless APs, and other industrial devices over extended distances.

Download Data Sheet

Features

  • Flexible SFP transceiver ports for uplink
  • IP67 standard with IK10 impact rated cast aluminum housing
  • IEEE 802.3bt 90W bt PoE with 6KV PoE surge protection
  • Supporting 10/100/1000Mbps data rates
  • Provision for Fiber Splice Tray inside the enclosure.
  • Covered under 3C3® Performance Warranty

Specifications

Dimensions (LxWxH) : 315.4 x 245.8 x 118mm
Mounting Type : Wall mount/ Poll Mount
Connectors : PF 3/4″ conduit cable gland – 1pc
M25 cable gland with 5x5mm holes – 1pc
M16 cable gland 1×6.5mm hole – 4pc

Enquiring For Product

Opti Power Outdoor Enclosure

The Opti power Enclosure comprises robust industrial-grade PoE switches designed for outdoor deployments, offering IP67-rated protection and 6KV PoE surge protection to ensure reliability in harsh conditions. These switches support flexible uplink options with SFP transceivers and provide data rates of up to 1Gbps. Housed in an IK10-rated aluminum enclosure, these switches are ideal for powering and connecting outdoor IP cameras, wireless APs, and other industrial devices over extended distances.
