Power Over Ethernet Surge Protector

Partcode: 47912

Description: Power Over Ethernet Surge Protector

Power over Ethernet surge protector is designed for POE power supply equipment, are widely used in the areas of wireless coverage, security monitoring etc. to protect the communication equipment’s POE port line from the impact of lightning Electromagnetic pulse, lightning electromagnetic pulse, switching overvoltage.

Features

  • Multi. Protection circuits, Gas-Tube+ TVS technology
  • Dual protection in Common module and different module
  • TVS array technology, low capacitance
  • Multi-Strike Capability

Specifications

Nominal operating voltage (Un) : 48V
Max continuous operating voltage Uc : 57V
Nominal discharge Current (8/20μs) In : 3kA
Max discharge current (8/20μs) Imax : 5kA
Dimension (LxWxH) : 76x50x25mm
Weight : 83g
Temperature : -40°C to 85°C
Relative Humidity : ≤95%
